JRJ Racing · Personally tuned by Jason
Texas Speed Chopacabra Remote Tuning
Get your Chopacabra build running with a tune based on your original stock read, exact camshaft and installed parts. Work directly with Jason through your private Tune Portal, from the first file to the revisions included with your service.

Personally tuned by Jason
Work directly with Jason—the owner and tuner who built and tuned these combinations in the shop.
Built around your vehicle
Your original stock read, exact cam and installed parts guide the tune.
Support through your Tune Portal
Keep your files and feedback together. Full Custom includes datalog review and up to five revisions.
Build your Chopacabra tune
Choose your vehicle and exact cam, select Base or Full Custom, then add your installed modifications.
HP Tuners required · equipment & credits
Requires supported HP Tuners MPVI2, MPVI3 or MPVI4 equipment for your exact vehicle. Hardware, licensing and required controller access are separate. RTD and TDN are not currently supported.
Vehicle first. Tune path before modifications.
Choose each part of the vehicle in order. After the camshaft, select your transmission, drivetrain, and PCM / controller. It’s okay to choose “I don’t know” for the controller. Then choose your tune type and supported modifications.
Doing an engine swap? Choose the original year, make, and model for your engine and PCM. Select “Swap Tune” below to enter the vehicle it’s going into.
Enter the specifications shown on your cam card. Durations must be measured at .050-inch tappet lift—not advertised duration.
MDS / DOD / AFM / DFM delete is included in your cam tune.
Enter the marked degrees (for example 0, 4 or 13), IDK or N/A. You can leave this blank and check out—we’ll help confirm it later. Don’t convert cam/crank degrees.
Select your PCM/controller. If you are unsure, choose “I don’t know.”
Your tuning and logging instructions will be delivered with each revision in your portal.
Bench Tuning / Mail-In Tuning supports confirmed P01 or P59 controllers only.
Choose how far you want to take it
Complete the vehicle fields above to choose your tune. Click a card to choose your service. Service selected. Choose your installed modifications below.
Selected service: scope, revisions & turnaround
Modifications & options · select your installed parts
This add-on covers the extra troubleshooting involved when changing engine and computer generations. Enter the vehicle the engine and PCM are going into below.
Paid selections are matched to the existing Shopify tune add-on products and added with the tune. Free and unlisted details stay attached to the order.
Downloadable .HPT files are limited to the selected supported camshaft calibration or supported DOD/AFM/MDS/VVT delete calibration. They do not include tuning changes for blowers, headers, intakes, injectors, fuel systems, heads, converters, transmissions, tire size, gear ratio, or other add-ons.
Downloadable files cover the listed cam or delete setup and do not include modification add-ons. If your vehicle has additional modifications, choose a Base Tune or Full Custom Remote Tune.
Shopify is verifying that the exact file is available for sale.
Open the library with this selection, then review the listed file details and all seven buyer requirements. If no matching file is listed, choose a remote tune built from your own read.
No closest file will be substituted. Choose a tune built from your own vehicle file instead.
Vehicle → exact cam → transmission → service → modifications
- Vehicle
- —
- Engine
- —
- Transmission / Drivetrain
- Not Provided / Not Provided
- Cam
- —
- VVT / phaser
- Tune Type
- —
- What vehicle is the engine and PCM going into?
- Modifications
- —
- Blowers
- LSA: No / Hellcat: No
- Package subtotal
- —
Before tax, shipping and any checkout discounts.
- Mon–Fri
- 9 a.m.–7 p.m.Eastern Time
- First tune
- 24–72 hoursWeekdays only
- Revisions
- 1–2 business days
Turnaround estimates vary with workload.
How timing works
Hours are usually Monday–Friday, 9 a.m.–7 p.m. Eastern. First tunes typically take 24–72 hours, counting weekdays only, once work begins and all required files and build details are ready. Weekends do not count toward turnaround estimates. Revisions typically take 1–2 business days depending on workload. These are estimates, not guaranteed deadlines.
From your build to your tune
Your tune, one step at a time
After checkout, your Tune Portal keeps the build details, files and conversation in one place.
- 01
Configure your tune
Use the builder to choose your vehicle, cam, service and installed modifications.
- 02
Upload your stock read
After purchase, use your Tune Portal to send the original read, cam card and complete build details.
- 03
Receive Revision 1
Your first tune usually takes 24–72 hours once work begins and all required files and build details are ready. Timing depends on workload. Weekends do not count toward these estimates.
- 04
Log, review and refine
Full Custom includes datalog review and up to five revisions for the purchased setup. Later submissions enter the queue in the order received; there is no guaranteed completion date.
Your private Tune Portal
One place for every file and conversation.
Upload your stock read, receive your tunes and send feedback directly to Jason. Full Custom datalogs and revisions stay with your order.
- Original reads & delivered tunes
- Datalogs & revisions
- Messages & order progress
How we work through your revisions
Your first tune usually takes 24–72 hours once work begins and all required files and build details are ready. This is an estimate based on workload. The tune is based on your original read and build details. Follow the delivery instructions and report how the vehicle behaves. Weekends do not count toward these estimates.
Base Tune includes two revisions. Full Custom includes datalog review and up to five revisions for the purchased setup. The next adjustment depends on the logs, feedback and issues identified; there is no fixed sequence that fits every build.
Revisions typically take 1–2 business days depending on workload and the adjustments required. This is an estimate, not a guaranteed deadline. Progress also depends on vehicle condition, installed parts, mechanical or installation issues, equipment, usable logs and feedback, and when you can test and upload them. Weekends do not count toward these estimates.
Logs and follow-up requests enter the queue and are handled in the order received. Waiting for logs, answers, parts or repairs pauses the next step.
JRJ will work carefully and in good faith to help with your purchased service. Remote tuning cannot guarantee perfection, mechanical stability or a specific power result. Review the service and refund terms before ordering.
What changes in the tune?
A cam tune starts with the engine and drivetrain you actually have. These are the areas JRJ reviews for the selected service.
Startup & idle
Starting airflow, idle control and in-gear behavior are reviewed against the cam and operating data. Describe when a stall, surge or restart problem occurs.
Airflow & fueling
Provide the intake, injectors, fuel and sensor information. Relevant airflow and fueling changes must be assessed with the correct component data.
Valve & torque control
Report any installed VVT limiter or lockout and cylinder-deactivation hardware, where equipped. The tune must reflect what is physically installed.
Transmission & converter
Identify the transmission, converter, tire diameter and axle ratio. Their effect on the driving experience belongs in the build information.
The controller, service selected and installed hardware determine which adjustments are available. tune is not a repair for incorrect mechanical installation.
Have these details ready
- Vehicle year, make, model and engine RPO
- Exact cam part number and supplied cam card
- Original stock read, controller and operating-system ID
- Installed cylinder-deactivation and VVT hardware, where equipped
- Transmission, converter, axle ratio and tire size
- Injectors, fuel type, intake, exhaust and other changes
Keep your original read unchanged. Identify unknown part numbers or settings before submitting your build.
Published test comparisons
Dyno comparisons
Texas Speed engine tests, redrawn in the JRJ style. Each result belongs to the listed test setup.
Texas Speed published comparison
LS 5.3 · Stock heads + TBSS intake
Gen IV 5.3 · 862 heads · LS6 springs · TBSS intake
Test details, source & plotted data
Texas Speed test: Gen IV 5.3, stock 862 heads, LS6 valve springs and a TBSS intake. The source labels the baseline cam TSP-315267-190-190-466-457-114. No vehicle model or fuel is identified on this sheet.
Approximate curves redrawn from the published sheet. These are Texas Speed engine tests, not JRJ customer results, wheel horsepower or a promised gain for your vehicle.
Original Texas Speed dyno sheet · Manufacturer test notes
View approximate plotted data
| Run | RPM | HP | lb-ft |
|---|---|---|---|
| Baseline cam | 3000 | 198 | 346 |
| Baseline cam | 3250 | 215 | 348 |
| Baseline cam | 3500 | 235 | 352 |
| Baseline cam | 3750 | 259 | 363 |
| Baseline cam | 4000 | 283 | 371 |
| Baseline cam | 4250 | 303 | 374 |
| Baseline cam | 4500 | 320 | 374 |
| Baseline cam | 4750 | 331 | 366 |
| Baseline cam | 5000 | 339 | 356 |
| Baseline cam | 5250 | 347 | 347 |
| Baseline cam | 5500 | 345 | 329 |
| Baseline cam | 5750 | 337 | 308 |
| Baseline cam | 6000 | 326 | 285 |
| Baseline cam | 6200 | 312 | 264 |
| Chopacabra | 3000 | 215 | 377 |
| Chopacabra | 3250 | 236 | 382 |
| Chopacabra | 3500 | 253 | 380 |
| Chopacabra | 3750 | 269 | 377 |
| Chopacabra | 4000 | 292 | 384 |
| Chopacabra | 4250 | 318 | 393 |
| Chopacabra | 4500 | 337 | 393 |
| Chopacabra | 4750 | 361 | 399 |
| Chopacabra | 5000 | 376 | 395 |
| Chopacabra | 5250 | 392 | 392 |
| Chopacabra | 5500 | 404 | 386 |
| Chopacabra | 5750 | 408 | 373 |
| Chopacabra | 6000 | 411 | 360 |
| Chopacabra | 6250 | 413 | 347 |
| Chopacabra | 6500 | 411 | 332 |
| Chopacabra | 6600 | 406 | 323 |
Torque curves were manually read from the original Texas Speed gallery sheets at the listed RPM points. Horsepower is calculated from those readings using HP = lb-ft × RPM / 5252 and checked against the plotted HP curve. Values are approximate, rounded to whole numbers; lines connect samples without extrapolation. These are not raw dyno logs. Exact Chopacabra peak callouts are transcribed separately from labels on the sheets; baseline peaks marked ≈ are visual estimates.
Texas Speed published comparison
Gen V 5.3 · L83 engine comparison
5.3L L83 · SuperFlow WinDyn · December 16, 2022
Test details, source & plotted data
Texas Speed SuperFlow WinDyn sheet dated December 16, 2022: 5.3L L83 baseline versus 25-TSPChopacabra-LT. The page identifies crank output. The sheet does not specify a vehicle, fuel, intake or exhaust combination.
Approximate curves redrawn from the published sheet. These are Texas Speed engine tests, not JRJ customer results, wheel horsepower or a promised gain for your vehicle.
Original Texas Speed dyno sheet · Manufacturer test notes
View approximate plotted data
| Run | RPM | HP | lb-ft |
|---|---|---|---|
| L83 baseline | 2500 | 176 | 369 |
| L83 baseline | 2750 | 198 | 379 |
| L83 baseline | 3000 | 220 | 386 |
| L83 baseline | 3250 | 241 | 389 |
| L83 baseline | 3500 | 267 | 400 |
| L83 baseline | 3750 | 293 | 410 |
| L83 baseline | 4000 | 319 | 419 |
| L83 baseline | 4250 | 347 | 429 |
| L83 baseline | 4500 | 366 | 427 |
| L83 baseline | 4750 | 379 | 419 |
| L83 baseline | 5000 | 394 | 414 |
| L83 baseline | 5250 | 402 | 402 |
| L83 baseline | 5500 | 407 | 389 |
| L83 baseline | 5750 | 411 | 375 |
| L83 baseline | 6000 | 409 | 358 |
| L83 baseline | 6250 | 401 | 337 |
| L83 baseline | 6500 | 396 | 320 |
| Chopacabra LT | 2500 | 176 | 369 |
| Chopacabra LT | 2750 | 197 | 376 |
| Chopacabra LT | 3000 | 234 | 410 |
| Chopacabra LT | 3250 | 256 | 414 |
| Chopacabra LT | 3500 | 273 | 410 |
| Chopacabra LT | 3750 | 301 | 422 |
| Chopacabra LT | 4000 | 335 | 440 |
| Chopacabra LT | 4250 | 364 | 450 |
| Chopacabra LT | 4500 | 386 | 451 |
| Chopacabra LT | 4750 | 408 | 451 |
| Chopacabra LT | 5000 | 427 | 449 |
| Chopacabra LT | 5250 | 442 | 442 |
| Chopacabra LT | 5500 | 452 | 432 |
| Chopacabra LT | 5750 | 460 | 420 |
| Chopacabra LT | 6000 | 466 | 408 |
| Chopacabra LT | 6250 | 463 | 389 |
| Chopacabra LT | 6500 | 454 | 367 |
Torque curves were manually read from the original Texas Speed gallery sheets at the listed RPM points. Horsepower is calculated from those readings using HP = lb-ft × RPM / 5252 and checked against the plotted HP curve. Values are approximate, rounded to whole numbers; lines connect samples without extrapolation. These are not raw dyno logs. Exact Chopacabra peak callouts are transcribed separately from labels on the sheets; baseline peaks marked ≈ are visual estimates.
Texas Speed published comparison
5.7 HEMI · Truck engine comparison
5.7 HEMI · truck intake / SRV · TSP 2-inch headers
Test details, source & plotted data
Texas Speed test: stock 5.7 HEMI, stock heads, truck intake with SRV, MDS/VVT delete and TSP 2-inch headers. The October 13, 2023 SuperFlow WinDyn sheet labels the baseline “5.7L Hemi Stock Truck VVT-SRV” and the cam run “25-TSPHemiCHOP.”
Approximate curves redrawn from the published sheet. These are Texas Speed engine tests, not JRJ customer results, wheel horsepower or a promised gain for your vehicle.
Original Texas Speed dyno sheet · Manufacturer test notes
View approximate plotted data
| Run | RPM | HP | lb-ft |
|---|---|---|---|
| Stock truck cam | 3000 | 234 | 410 |
| Stock truck cam | 3250 | 264 | 427 |
| Stock truck cam | 3500 | 293 | 440 |
| Stock truck cam | 3750 | 321 | 449 |
| Stock truck cam | 4000 | 345 | 453 |
| Stock truck cam | 4250 | 366 | 452 |
| Stock truck cam | 4500 | 384 | 448 |
| Stock truck cam | 4750 | 397 | 439 |
| Stock truck cam | 5000 | 411 | 432 |
| Stock truck cam | 5250 | 422 | 422 |
| Stock truck cam | 5500 | 433 | 413 |
| Stock truck cam | 5750 | 435 | 397 |
| Stock truck cam | 6000 | 434 | 380 |
| Stock truck cam | 6250 | 431 | 362 |
| Stock truck cam | 6300 | 427 | 356 |
| HEMI Chopacabra | 3000 | 236 | 413 |
| HEMI Chopacabra | 3250 | 268 | 433 |
| HEMI Chopacabra | 3500 | 297 | 446 |
| HEMI Chopacabra | 3750 | 325 | 455 |
| HEMI Chopacabra | 4000 | 352 | 462 |
| HEMI Chopacabra | 4250 | 375 | 463 |
| HEMI Chopacabra | 4500 | 396 | 462 |
| HEMI Chopacabra | 4750 | 413 | 457 |
| HEMI Chopacabra | 5000 | 427 | 448 |
| HEMI Chopacabra | 5250 | 443 | 443 |
| HEMI Chopacabra | 5500 | 457 | 436 |
| HEMI Chopacabra | 5750 | 465 | 425 |
| HEMI Chopacabra | 6000 | 475 | 416 |
| HEMI Chopacabra | 6250 | 478 | 402 |
| HEMI Chopacabra | 6500 | 479 | 387 |
| HEMI Chopacabra | 6750 | 479 | 373 |
| HEMI Chopacabra | 6800 | 478 | 369 |
Torque curves were manually read from the original Texas Speed gallery sheets at the listed RPM points. Horsepower is calculated from those readings using HP = lb-ft × RPM / 5252 and checked against the plotted HP curve. Values are approximate, rounded to whole numbers; lines connect samples without extrapolation. These are not raw dyno logs. Exact Chopacabra peak callouts are transcribed separately from labels on the sheets; baseline peaks marked ≈ are visual estimates.
Have a different engine or Chopacabra cam card?
Send your exact engine and cam part number for application review. The examples above identify specific cams and test builds.
Straight answers
Chopacabra tuning questions
Should I choose Full Custom or Base Tune?
Full Custom includes datalog review and up to five revisions for the purchased setup. Base Tune provides a vehicle-specific starting tune with two revisions. Choose Full Custom when your combination needs continued drivability review and refinement.
How do I send my files and communicate with Jason?
After purchase, use your customer Tune Portal for your original stock read, build information, datalogs, delivered tunes, messages and revisions. Use the portal link above to access your account.
Does every Chopacabra use the same tune?
The original LS truck cam, NSR versions, dedicated 6.0 grinds, rectangular-port LS cam, Gen V LT and HEMI cam have different specifications. Send the complete part number and your own cam card. Engine, controller and supporting parts also matter.
Does NSR mean I can skip tune?
NSR identifies a cam designed for the manufacturer’s specified stock-spring setup. It does not remove the need to tune your actual engine. Include the exact NSR version and installed hardware in the build details.
Can I keep my stock torque converter?
Texas Speed describes several Chopacabra versions as factory-converter friendly. It recommends a 2600+ stall for best performance with the dedicated 6.0 cathedral-port grind. Match the recommendation to the exact cam, transmission and vehicle use.
What horsepower will my truck make?
Texas Speed publishes results for specific test engines. Those gains are not a promised output for every Chopacabra vehicle. Your engine, fuel, hardware and test conditions determine the result; remote tuning uses your actual build and the feedback included with your selected service.
Manufacturer sources & exact cam cards
Confirm your supplied cam card before selecting hardware or a tune. These links identify the source specifications, not JRJ product or service prices.
